PBT
Polybutylene terephthalate
Polybutylene terephthalate (PBT) is a polyester composed of terephthalic acid and 1,4-butanediol. It is a significant thermoplastic polyester and one of the five major engineering plastics. PBT is a milky white semi-transparent to opaque, semi-crystalline thermoplastic polyester with high heat resistance. However, it is not resistant to strong acids, strong alkalis, organic solvents, and is flammable, with a tendency for high-temperature decomposition.

Donghua Tianye adopts innovative production process control technology and a strict quality control system. Continuous dedicated lines of high-capacity production ensure extremely stable PBT product quality. This stability effectively enhances the hydrolysis resistance and thermal stability of downstream products, significantly improving their processing performance and mechanical properties, thus ensuring stable quality throughout the production process. Our product specifications cover three common viscosity grades: low viscosity, medium viscosity, and high viscosity, and viscosity specifications can be customized according to customer needs.
PBT Characteristics
  • Excellent mechanical
    properties
  • Excellent water absorption
  • Excellent electrical properties
  • Excellent chemical resistance
  • Excellent machinability
PBT Product Indicators
PropertiesUnitProduct Indicators
Masterbatch of Melt Flow Index or reinforced modified materials for the electronic, electrical, and automotive engineering plastics industrySpinning, high

grade soft

brush

Fiber optic casing and engineering plastics fields

DT2083DT2087DT2090DT2095DT20100DT20120
Viscosityd1/g

0.830

  ±

0.015

0.870

  ±

0.015

0.900

  ±

0.015

0.950

  ±

0.015

1.000

  ±

0.015

1.200

  ±

0.015

Melting point223±2
Carboxyl End Groupmol/t≤30
Color(L)≥90
Color(B)
≤3
Water Content%
≤0.2
Ash Contentmg/kg
≤200
Hundred-grain weightg2.2±0.2
Densityg/cm³1.28-1.32
Melt index(250℃; 2.16kg)g/10min65-8055-6442-5333-4023-3210-15
Tensile strengthMPa≥50
Elongation at break%
≥60≥100
Notched impact strength
(cantilever beam)
kJ/㎡≥4
Promotion of PBT Applications
Electrical Appliance Applications

- Air Fryer
- Electric Lamp Shade
- Steam Iron
- and more

Automotive Supplies

- Car Ignition Coil
- Boneless Car Wipers
- Rearview Mirror Shell
- and more

Aircraft Supplies:

- Optical Cable Shell
- Solenoid Valve Shaft
- and more

Communication Equipment Supplies:

- Mobile Phone Cases
- Integrated Modules for Program-Controlled Phones
- Wiring Boards
- Power Tools
- and more

Other Promotion of PBT Applications
